Hydraulic Braking Electric Power Dry Shotcrete Machine OEM Accepted Concrete Sprayer
-
Highlight
Hydraulic Braking Dry Shotcrete Machine
,Electric Power Concrete Sprayer
,OEM Accepted Gunite Machine
-
Product TypeDry-mix Shotcrete Machine
-
MotorCustomized Available
-
Warranty1 Year
-
Applicable MaterialsDry Concrete
-
Drive TypeDiesel Engine Or Electrical Or Air
-
Output3-9m3/h
-
Spraying Hose Id57/64mm
-
Weight750kg
-
Max Aggregate Size20mm
-
KeywordsRemote Conveying Gunite Machine
-
Dry TypeDedusting
-
After Warranty ServiceOnline Support
-
Conveying Pipe Id51/57/64mm
-
Place of OriginCHINA
-
Brand NameKEMING
-
CertificationCE
-
Model NumberKPZ
-
Minimum Order Quantity1
-
Price1000-3000 USD
-
Packaging DetailsWooden case
-
Delivery Time5-8 days
-
Payment TermsL/C,T/T
-
Supply Ability5 sets per month
Hydraulic Braking Electric Power Dry Shotcrete Machine OEM Accepted Concrete Sprayer
Dry Shotcrete Machine Overview
This electric-powered dry shotcrete machine features hydraulic braking for operator safety and immediate emergency stops. Designed for OEM customization, it offers versatile applications with consistent concrete spraying through integrated grouting pump and mortar spraying systems. The low rebound spraying gun minimizes waste while maintaining efficiency.
Key Features
- Product Name: Dry-mix Shotcrete machine
- Rated Working Pressure: 0.2-0.5MPa
- Capacity: Varies with model specifications
- OEM customization accepted
- Dedusting Part Capacity: 800m³/h
- Hopper Capacity: 120L
Technical Specifications
| Model | KPZ500 | KPZ-2 | KPZ-3 | KPZ-4 | KPZ-5/PC5I | KPZ-7 | KPZ-9 |
|---|---|---|---|---|---|---|---|
| Output (m³/h) | 0.5 | 2 | 3 | 4 | 5 | 6 | 8 |
| Max. Conveying Distance (m) | 100 | 200 | 200 | 230 | 200 | 150 | 100 |
| Max. Aggregate Size (mm) | 12 | 15 | 15 | 18 | 20 | 20 | 20 |
| Hose Inner Diameter (mm) | Φ32 | Φ38 | Φ38/51 | Φ38/51 | φ51 | Φ57 | Φ57/64 |
| Air Consumption (m³/min) | 5-6 | 7-8 | 8-10 | 10-12 | 10-12 | 12-15 | 12-15 |
| Motor Power (KW) | 2.2/3 | 3 | 4 | 5.5 | 5.5 | 7.5 | 7.5 |
Applications
The KEMING KPZ dry shotcrete machine excels in mining tunnels, underground construction, slope stabilization, tunnel lining, and swimming pool construction. This CE-certified crawler machine operates effectively in tight spaces and difficult-to-reach areas, with power options including electric, diesel, or air motor configurations.
Technical Support & Services
- Installation and commissioning
- Operator training programs
- Maintenance and repair services
- Remote monitoring and troubleshooting
- Parts replacement and supply
Packaging & Shipping
Each machine is securely packed in wooden crates for transportation protection. We partner with reliable freight carriers for safe delivery, providing tracking numbers for shipment monitoring. Shipping costs are calculated based on destination and crate weight.
Frequently Asked Questions
What is the brand name of the dry shotcrete machine?
The brand name is KEMING.
What is the model number?
The model number is KPZ.
Where is the machine manufactured?
The machine is made in China.
Is the machine CE certified?
Yes, it is CE certified.
What is the minimum order quantity?
The minimum order quantity is 1 unit.
What is the price range?
The price ranges from $2,000 to $5,000 USD.
What are the payment terms?
Payment terms include L/C and T/T.
What is the supply capacity?
Supply ability is 5 sets per month.
What is the delivery time?
Delivery time is 5-8 days.
How is the machine packaged?
The machine is packaged in a wooden case.
