Refractory Dry Shotcrete Machine 2~3 M3/H Mini Gunite Refractory Equipment
-
Highlight
Refractory Dry Shotcrete Machine
,3 M3/H Refractory Dry Shotcrete Machine
,Mini Gunite Refractory Equipment
-
TheoryRotory Shotcrete Machine
-
Power SourceElectric
-
Voltage220/380/440V
-
CapacityVery With The Model
-
Operating Pressure0.2-0.6MPa
-
Power TypeElectric
-
Water Cement Ratio≤0.4
-
Dry TypeDedusting
-
EngineThree Phase Electrical Engine
-
Max Aggregate Size20 Mm
-
TypeDry Shotcrete Gunite Machine
-
ColorBlue/White/Customized
-
MotorCustomized Available
-
Conveying Pipe Id51/57mm
-
Max. Vertical Conveying Distance20m
-
Place of OriginChina
-
Brand Namekeming
-
CertificationCE, ISO, MA
-
Model NumberPS2I-D
-
Minimum Order Quantity1 set
-
Price1000-2500 USD
-
Packaging Detailsnude or wooden box packing
-
Delivery Time5-8 days
-
Payment TermsL/C, T/T
-
Supply Ability20 sets per month
Refractory Dry Shotcrete Machine 2~3 M3/H Mini Gunite Refractory Equipment
Refractory Dry Shotcrete Machine 2~3 M3/H Mini Gunite Refractory Equipment
Introduction:
The PS2I-D rotor concrete spraying machine has the characteristics of advanced technology, reasonable structure, stable performance, convenient operation and maintenance, and long service life. It is a miniature spraying machine specially designed for refractory materials and new thin spraying materials.
It is widely used in the spraying construction of concrete in tunnels, culverts, subways, hydropower projects, underground projects and coal mine swamp mine tunnels.
Specification:
| Item | unit | parameter |
| Capacity | m3 /h | 2 |
| Air pressure | MPa | ≥0.5 |
| Air consumption | m 3 /min | ≥8 |
| Horizontal conveying distance | m | 100 |
| Max. Aggregate size | mm | 20 |
| Dimension | mm | 1250×500×850 |
| Weight | kg | 260 |
Company introduction:
Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd.
Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd.is a subsidiary of Henan Coal Scientific Research Institute Co., Ltd.It is the first company in China to develop and produce shotcrete machines. It is one of the national standards for the development of spraying industry.
Achievements: It has more than 20 national invention patents and utility model patents, and more than 10 identification of relevant departments. It has won 8 awards from coal associations and provincial departments, and won the Henan Provincial Science and Technology Progress Award.In 2014, “ Keming ” brand won the famous trademark of Henan Province. It has been awarded ISO9001 Quality Management System Certification, OHSAS 18001 Occupational Health and Safety Management System Certification, ISO14001 Environmental Management System Certification and CE Certification.
Service: mechanical and electrical products, chemical technology, the development and manufacture of mining products, technical research of energy conservation and environment protection technology, and relative consultation service.
Application:
Our products are mainly applied in water conservancy and hydropower engineering, subway engineering, air-raid shelter construction, municipal construction, environmental greening projects, tunnel and bridge maintenance, slope maintenance, blast-furnace refractories spraying operations, mining concrete spraying operations, etc.
Main Products:
wet/dry shotcrete machine, plastering machine, concrete/shotcrete pump, grouting pump, cement pump,mortar pump, slurry pump, hose pump, cement/concrete mixer, concrete foaming machine etc.
Exhibition:
FAQ:
1. Q: Which shotcrete machine model should we choose?
A: To recommend the most suitable model, please let us know your requirements and the details of your project, then will give you the professional suggestions soon.
2. Q: What is the vulnerable part? How many spares should we prepare?
A: After long-time running, the rubber piston and cylinder sleeve may get worn. We will offer some spares for free.
Referring to the service life of each part, we will put a rough estimate of requested spares according to your project scale.
3. Q: Can we have customized model?
A: Yes. Customized production and OEM production are available according to your actual requirements.
4. Q: Do i need technical skills to operate this machine?
A: Yes. Please read the Operation Instruction for some basic technical skills before operating this machine, and contact us if any operation procedure is unclear.
5. Q: What should we do if there are some problems with the machine?
A: The Operate Instruction will help with routine maintenance and common problems.
Also, you can contact us for technical instruction by email, instant messenger or live video etc.
6. Q: What is the lead time?
A: 1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
7. Q: How about the package?
A: The machine will be wrapped by plastic film and packed by fumigation-free wooden case along with spare parts.
8. Q: How to place an order?
A: Both online order and offline order are acceptable.
It is suggested to place online order with a Trade Assurance to get full protection for first order.
9. Q :How to pay for this order?
A: Generally, TT, 30% deposit 70% before shipment;
L/C at sight (high bank charge, not suggest, but acceptable);
100% TT in advance (especially for small amount and spare parts etc.)
Our products are sold all over the world, you can rest assured.
